    Selective Heavy Duty Shuttle Metal Pallet Racks warehouse shelving Steel Q235

    Ask Lasest Price
    Brand Name : NOVA
    Model Number : NH
    Certification : ISO9001; ISO14001; CE
    Price : Negotiable
    Delivery Time : 8000 TONS PER MONTH
    • Product Details
    • Company Profile

    Selective Heavy Duty Shuttle Metal Pallet Racks warehouse shelving Steel Q235

    Semi-automatic Shuttle System Drive-in Racking

    A shuttle system consists of supporting rack, shuttle rails and a shuttle cart. The shuttle cart runs on the rails and is propelled by an electric motor. It also has a platform on the top that can lift up and down. The lifting action is required to lift a pallet that is placed on the rail and then the electric motor moves the cart with the pallet on top into the rack in order to deposit the pallet in its right position.


    All the movements of the shuttle cart are controlled with a hand held remote control. The shuttle cart is placed in the desired lane with a forklift.


    Advantages

    Radio Shuttle Cart is a fully programmable deep lane storage and retrieval system used to transport pallets within a racking structure for maximum storage and throughput of bulk stored items. Radio shuttle rack system allows for more pallets to be stored in a given area when compared to normal static rack.


    It also minimizes damage to the rack because the forklift does not have to travel into the racking, as is the case with drive-in rack. Accessibility is increased because all the levels can be accessed at any time. In a drive-in rack system the bottom level must be cleared first in order to be able to access the higher levels.


    It can provide the perfect solution to dense storage situations. One of the conventional methods would be to install drive in racking which is great at space utilization but can sometimes inhibit efficiencies when storing the deep pallets as well as potential damage to uprights.


    It gives the same space utilization but removes the inefficiencies and risk of damages. All the forklift operator needs to do is place a pallet onto a shuttle position and activate the shuttle and it does the rest of the work, freeing up the operator to complete other tasks.


    Material
    Steel Q235
    Loading Capacity
    Customized and up to 4,000 Kg UDL/level
    Racking Height
    Customized and up to 11,000 mm
    Racking Depth
    700-1,200 mm
    Beam Length
    Customized and up to 3,600 mm
    Racking Finish
    Frames (Powder Coated or Pre-galvanized) + Bracings (Powder Coated or Pre-galvanized) + Beams (Powder coated)
    Packing Details
    Standard export seaworthy packing

    Selective Heavy Duty Shuttle Metal Pallet Racks warehouse shelving Steel Q235

    Packing & Delivery

    Packing Details : Packed by wooden bars, crates, metal stripes, films for bulk goods, and cartons for accessories. Package is also customized. A 40'GP is available for around 20-25 tons materials and accounts for up to 55 CMB

    Delivery Details :Within 30 days


    Advantage:

    1. Low MQQ: Meeting actual small requests;

    2. OEM Acceptable: We can produce you design;

    3. Good service: We treat clients as friend;

    4. Good quality: We have strict quality control system. Good reputation in the market;

    Fast delivery: Scientific production arrangement to ensure the fast delivery.

    FAQ

    1. Q: Where is your factory located? How can I visit there?
    A: Our factory is located in Nanjing City, Jiangsu Province, China, close to Shanghai. You can fly to Nanjing or Shanghai airport directly. You are warmly welcome to visit us whenever you are available!


    2. Q: What is delivery times?

    A: It depends on the order quantity and racking types


    3. Q: What is the term of payment?

    A: As general, 30% T/T down payment and balance before shipping.
