    NOVA Logistics Equipment Large Scale Industrial Heavy Duty Racking

    Ask Lasest Price
    Brand Name : NOVA
    Model Number : Teardrop racks
    Certification : CE, ISO, TUV, AS4084
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 600000kg
    Delivery Time : 3-4 weeks
    • Product Details
    • Company Profile

    NOVA Logistics Equipment Large Scale Industrial Heavy Duty Racking

    Large Scale Warehouse Logistics Equipment Racking/Nanjing Origin

    Warehouse Heavy Duty Pallet Racking 50.8mm Pitch with 10 Years Warranty


    Nanjing Supplier NOVA brand

    Pallet Racking is a system of beams and uprights used to support pallets in a warehouse .There are numerous versions of pallet racking .The most common is adjustable racking (APR),also called Selective Pallet Racking, here we will introduce Global Standard types of Pallet Racking Systems ,we mainly export to Europe and Mideast , Asia markets etc.

    Global Standard Pallet Racking provides efficient use of storage space for palletized loads. All steel are produced from National Large Scale Steel Group company with stable quality. With the wide range of options and components available, Global Standard Pallet Racking Systems can be made to meet your precise needs.


    Haili Industrial Heavy Duty Racking/Iron Storage Shelf/Warehouse Metal Shelves


    The heavy type of pallet rack is the most cost effective storage system with the lowest equipment and capital costs. It provides direct access to all pallets for 100% accessibility and good stock rotation.

    1. Features:

    1)Beam levels are adjustable in 50mm pitch interval.

    2)Different sizes, various specifications and colors are available according to customers’ different needs.

    3)Maximizes space use ratio in any warehouse configuration while retaining optimum product accessibility.
    4)Strength and rigidity prevents compression damage to goods.
    5)Bottom level of pallets can be stored on the floor, lowering structure costs.

    2. Material:High grade Q235B Steel
    3. Finish:High-quality Powder Coating Finishing.
    4. Load Capacity & Dimension:Loading capacity: 500-4500 kgs UDL/beam level.
    Height: 1000-12000mm
    Depth: 800-1200mm
    Length: 1000-4000mm
    Specail sizes also avaiable to specific storage needs.
    5. Main Parts Specs:1) Uprights:75*66mm, 90 *66mm, 100 *66mm, 120 *66mm, etc.
    2) Box beams: 80*50mm, 90*50mm, 100*50mm, 110*50mm, 120*50mm, 130*50mm, 140*50mm, etc.,
    3) Horizontal & diagonal bracings, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components.
    6. CE certified.Haili® storage metal rack, CE certified, is designed and manufacturered to European Racking Code FEM 10.2.02, the Australian Standard - Steel Storage Racking AS4084-2012, and American racking standards.
    7. Quick Delivery.

    Within 15 days for ordinary order quantity. Big production capacity allow us in a position to make quick delivery.


    For a quick quotation, please let us know below info:
    1)- your warehouse drawing (if available)
    2)- warehouse door site
    3)- length, width, clear height of the warehouse
    4)- the size and weight of the pallet (after loading)
    5)- it's better know the pallet forklift access size


    Product nameWarehouse shelving heavy duty racking system
    Features

    Mater:Q235B Steel

    Size(mm): Customized

    Load capacity: 1500-4500KG

    Color: Customized

    OEM/ ODM: Accepted

    Feature: Corrosion Protection

    SpecificationThis shelf with popular design, safe to keep goods.
    Different thickness,size,layers,and colors are available for you to choose.
    OthersPayment terms: 30% deposit upon signing the contract,the balance will be cleared by T/T before delivery.
    Delivery Terms: Upon factory
    Delivery Time: 30 days after receiving the deposite
